Commercial Paddle Sweeps provide a safe and reliable way to clean out your bin. The zero-entry control system allows for automatic or manual operation saving you time and money. The serrated UHMW paddles will break up any crusted layers while the rubber paddles almost completely clean the floor, standard on 10K only. Available in 5K and 10K capacities.
- Heavy-Duty Zero-Entry Explosion-Proof Rotating Contact provides power to the sweep, there is no need to enter the bin
- Up to 10,000 BPH
- Patented pivot point allows the sweep to “free-float” to account for variations in concrete (U.S. Patent #9,327,921)
- Heavy-duty Frame designed to provide optimal strength to withstand the intense pressure of deep grain depths
- Heavy duty take-up bearings supply long lasting durability and strength
- Shallow Center Sump is cast in place and requires less concrete, saving you construction costs. Deeper design is also available
- Explosion-Proof Motors and industrial grade gear box and bearings for greater safety and durability
- Heavy-Duty Zero-Entry Explosion-Proof Rotating Contact provides power to the sweep. There is no need to enter the bin
- Emergency Stop Button for enhanced safety
- Zero-Entry Automatic Touch Screen Controls allow the pushers’ start and stop points to be user programmed on the touch screen to keep the paddles running efficiently based on a particular situation. In automatic mode, the controller senses chain load and advances the sweep without overloading the chain motor, preventing spinning of the pusher tires, which can cause extra wear. The sweep controls also have a manual mode that allows the operator to control sweep advancement.
- Programmable Logic Controller (PLC) provides greater reliability
- Industrial Grade Pushers are equipped with explosion-proof motors and foam-filled tires for safety and durability. Pusher speeds are based upon their location on the sweep through the use of varying gear ratios. This results in the pushers applying uniform pressure to the sweep, reducing wear on the inside pushers.
- Heavy-Duty Steel Wheels with bronze bushings
- Heavy-Duty Frame designed to provide optimal strength to withstand the intense pressure of deep grain depths
- Adjustable Rubber-Tipped Scraper behind the paddles maximizes the amount of grain collected along the bin floor
- Heavy-Duty frame
- Industrial grade pushers
- Patented pivot point
